34 Matrox Display Wall – User Guide
Connecting your Mura IPX Series capture
card
This section describes how to connect your Mura IPX Series 4K Capture and IP Encode/Decode and
your Mura IPX Series 4K Capture and IP Decode card.
Once all your cards are connected, restart your system and install your Matrox software (see
“Installing your software”, page 53).
Supported hardware More information
Input/Output
Mura MPX-4/4, MPX-4/2 See page 39.
Mura MPX-SDI See page 41.
Input
MURAIPXI-E4SF, MURAIPXI-E4SHF See page 35.
MURAIPXI-E2MF, MURAIPXI-E2MHF,
MURAIPXI-D2MF, MURAIPXI-D2MHF
See page 36.
MURAIPXI-E4JF, MURAIPXI-E4JHF,
MURAIPXI-D4JF, MURAIPXI-D4JHF
See page 37.
Mura MPX-V16, MPX-V8 See page 45.
Output
Mura MPX-4/0 See page 43.
C900 See page 48.
C680 See page 49.
Console
P690 PCIe ×16 See page 77.
P690 Plus LP PCIe ×16
(dual-monitor cable)
See page 78.
P690 Plus LP PCIe ×16
(quad-monitor cable)
See page 79.
M9120 PCIe ×16, M9125 PCIe ×16 See page 80.
M9120 Plus LP PCIe ×1 / ×16 See page 81.
M9140 LP PCIe ×16 See page 83.
M9128 LP PCIe ×16 See page 84.
M9138 LP PCIe ×16, M9148 LP PCIe ×16 See page 85.
Note
: To make sure your cables are securely attached to your Matrox cards, use a cable retention
bracket. To purchase a cable retention bracket, contact your Matrox representative. For more
information, see “Appendix C – Matrox secure cable solution”, page 87.
