30 Matrox Display Wall – User Guide
Mura MPX-4/4, MPX-4/2, and MPX-4/0
Your Matrox Mura MPX Series cards have four LED indicators labeled (
Good
,
12V
,
Fail
,
CFG_Done
).
The following describes the behavior of these LED indicators.
LED Color Behavior
Good Green Card is active.
12V Green Card is properly powered.
Fail Red
Card may have insufficient power. Try restarting your system.
If after restarting your system the LED indicator is still red,
contact your vendor for technical support (see “Customer
support”, page 94).
CFG_Done Black (off)
Problem occured while programming your card. For more
information, contact your vendor (see “Customer support”,
page 94).
