Matrox C Series - Mura IPX Series 4 K Displayport Capture and IP Encode;Decode Cards

Matrox Display Wall – User Guide 63
Mura IPX Series 4K DisplayPort Capture and IP Encode/Decode cards
MURAIPXI-E2MF • MURAIPXI-E2MHF
Operating systems supported
Windows
®
10 64-bit, Windows
®
10 IoT, Windows
®
Server
®
2016, Windows
®
7 64-bit, Windows
®
Server
®
2008 R2,
Windows
®
Embedded Standard 7 64-bit, Windows
®
Embedded Enterprise 7 64-bit, Linux
®
Card type
PCIe ×16 2.0
(×16 mechanical, ×8 electrical)
Form factor ATX
Memory 8 GB
Connectors 2× DisplayPort 1.2, 1× 100/1000 Base-T RJ45 Ethernet Port
Outputs supported —
Inputs supported 2× DisplayPort 1.2 + IP
Maximum DisplayPort input
resolutions
4096 × 2160 @ 60 Hz,
4096 × 2160 @ 30 Hz,
3840 × 2160 @ 60 Hz,
3840 × 2160 @ 30 Hz
IP stream support RTSP, RTP, SRT, MPEG-2 TS
Video CODEC engine H.264
Audio stream support 9
*
* Supported only with C-Series.
H.264 decode
†‡
† Standard resolutions listed above. Support for custom resolutions available. For specific requirements, contact your Matrox
representative.
‡ In YUV 4:2:0, 12 bits per pixel (8 bits per component).
two 3840 × 2160 @ 60 Hz,
four 3840 × 2160 @ 30 Hz,
eight 1920 × 1080 @ 60 Hz,
sixteen 1920 × 1080 @ 30 Hz,
or numerous SD channels
H.264 encode
*†‡
two 3840 × 2160 @ 60Hz,
four 3840 × 2160 @ 30Hz,
eight 1920 × 1080 @ 60Hz,
sixteen 1920 × 1080 @ 30Hz,
or numerous SD IP streams
Maximum card dimensions
L: 9.02 in / W: 0.75 in / H: 4.376 in
L: 22.9 cm / W: 1.91 cm / H: 11.1 cm
Regulatory compliance Class B: FCC, CE, RCM, VCCI, ICES-3, CSA, KC
