Matrox Display Wall – User Guide 47
Connecting your C-Series card
This section describes how to connect your Matrox C-Series card.
Once all your cards are connected, restart your system and install your Matrox software (see
“Installing your software”, page 53).
Supported hardware More information
Input
MURAIPXI-E4SF, MURAIPXI-E4SHF See page 35.
MURAIPXI-E2MF, MURAIPXI-E2MHF,
MURAIPXI-D2MF, MURAIPXI-D2MHF
See page 36.
MURAIPXI-E4JF, MURAIPXI-E4JHF,
MURAIPXI-D4JF, MURAIPXI-D4JHF
See page 37.
Output
C900 See page 48.
C680 See page 49.
Console
M9120 PCIe ×16, M9125 PCIe ×16 See page 80.
M9120 Plus LP PCIe ×1 / ×16 See page 81.
M9140 LP PCIe ×16 See page 83.
M9128 LP PCIe ×16 See page 84.
M9138 LP PCIe ×16, M9148 LP PCIe ×16 See page 85.
Note
: To make sure your cables are securely attached to your Matrox cards, use a cable retention
bracket. To purchase a cable retention bracket, contact your Matrox representative. For more
information, see “Appendix C – Matrox secure cable solution”, page 87.
