Matrox Display Wall – User Guide 71
M9128 LP PCIe M9138 LP PCIe M9148 LP PCIe
Operating systems
supported
Windows
®
10, Windows
®
Server
®
2016, Windows
®
Server
®
2008 R2,
Windows
®
7, Windows
®
Embedded Standard 7, and Linux
®
Digital monitor
support
DisplayPort, DVI DisplayPort, DVI DisplayPort, DVI
Memory 1 GB 1 GB 1 GB
Card type PCIe ×16 PCIe ×16 PCIe ×16
Form factor Low-profile Low-profile Low-profile
Monitors supported 234
Connectors 2× DisplayPort 3× Mini DisplayPort 4× Mini DisplayPort
Maximum resolution
2560 × 1600 @ 60 Hz
(DisplayPort)
1920 × 1200 @ 60 Hz
(DVI)
2560 × 1600 @ 60 Hz
(DisplayPort)
1920 × 1200 @ 60 Hz
(DVI)
2560 × 1600 @ 60 Hz
(DisplayPort)
1920 × 1200 @ 60 Hz
(DVI)
Maximum card
dimensions
L: 6.600 in / H: 2.712 in / W: 0.750 in
L: 16.80 cm / H: 6.90 cm / W: 1.91 cm
Regulatory
compliance
Class B: FCC, CE, RCM, VCCI, ICES-3, CSA, KC
P690 PCIe ×16 P690 Plus LP
PCIe ×16
Operating systems
supported
Windows
®
Embedded Standard 7 (64-bit), Windows
®
7 Professional (64-bit),
Windows
®
7 Professional for Embedded Systems (64-bit),
Windows
®
Server
®
2008 R2 (64-bit)
Digital monitor
support
DVI DVI
Memory 128 MB 256 MB
Card type PCIe ×16 PCIe ×16
Form factor Full height Low-profile
Monitors supported 22 DVI / 4 HD-15
Connectors 2× DVI 1× LFH-60
Maximum resolution
1920 × 1200 @ 60 Hz (DVI)
2048 × 1536 @ 60 Hz (HD-15)
1920 × 1200 @ 60 Hz
(DVI, 4× HD-15))
2048 × 1536 @ 60 Hz (2× HD-15)
Maximum card
dimensions
L: 6.6 in / H: 4.376 in /
W: 0.75 in
L: 16.76 cm / H: 11.12 cm /
W: 1.91 cm
L: 6.6 in / H: 2.712 in /
W: 0.75 in
L: 16.76 cm / H: 6.89 cm /
W: 1.91 cm
Regulatory
compliance
Class B: FCC, CE, RCM, VCCI, ICES-3, CSA, KC
