Appendix D, Matrox MXO2 Supported Output Formats
All other custom formats
(cont’d)
7
1080PsF @ 23.98 fps
NTSC, 480p @ 59.94 fps
5
, 720p @ 59.94 fps, 1080i @ 29.97 fps, or
1080p
3
/PsF @ 23.98 fps
1080p @ 23.98 fps
3,4
1080PsF @ 24 fps
4,6
1080p/PsF @ 24 fps
3,6
1080p @ 24 fps
3,4
1080PsF @ 25 fps
PAL, 576p @ 50 fps
5
, 720p @ 50 fps, or 1080p
3
/PsF @ 25 fps
1080p @ 25 fps
3,4
1080PsF @ 29.97 fp
NTSC, 480p @ 59.94 fps
5
, 720p @ 59.94 fps, or 1080p
3
/PsF @ 29.97 fps
1080p @ 29.97 fps
3,4
1080p @ 30 fps
3,4
1080p @ 30 fps
3
1
Main output on MXO2 Mini is always analog.
2
Secondary output on MXO2 Mini is always HDMI.
3
1080p is supported on the HDMI and SDI outputs only.
4
Not available on MXO2 Mini.
5
480p @ 59.94 fps and 576p @ 50 fps are supported on the HDMI output only.
6
1080PsF @ 24 fps is supported on the SDI output only.
7
For the best results, you should select a video output format with a frame rate that matches or is compatible with
your sequence’s frame rate.
Matrox MXO2 output
Sequence video
format
Main output
1
Secondary output
2
