Repair Comet Executive Gas
7-18
Compression Roll Pressure
Adjustment
Required Tools
Wrenches: 9/16” (2)
Perform only when the unit is OFF
with power disconnected and COOL.
1. Turn power OFF at the main disconnect
switch.
2. Open both endframe doors.
3. Locate the adjustable springs attached to
their bracket slots each endframe (Figure
7-15, A).
4. Loosen the locknut (Figure 7-15, B).
5. Turn the adjustment nut (Figure 7-15, C)
clockwise to increase the tension; coun-
terclockwise to decrease.
6. Tighten the locknut once the adjustment
has been made.
7. Close and secure both endframe doors.
WARNING
Never operate the unit unless
all safety covers are in place
and all safety equipment is
working correctly.
8. Perform Compression Roll Pressure
Check on page 7-17.
9. Make further adjustments as necessary.
Figure 7-15: A compression roll tensioning spring is
located in each endframe.
C
B
A
