Operating Principles Comet Executive Gas
5-4
Electrical Panel
The electrical panel (Figure 5-3) is located
inside the right endframe. The table below
provides an explanation of each item indicated
in the picture.
ELECTRICAL PANEL COMPONENTS
Schematic Description
CR1 Control Relay - Run Latch
DSC1 Main Disconnect Switch
FB1 Fuse Block - Main Drive Motor Inverter
FB2 Fuse Block - Transformer T1
INV1 Inverter - Drive Motor
MP1 Motor Protector - Exhaust Blower Motor
T1 Transformer - 24 V Control Circuit
Figure 5-3: Electrical panel power system components -inside right endframe.
T1
FB1
DSC1
INV1
MP1
CR1
FB2
