Comet Executive Gas 3031-005h
PL-13
Contact Shoe Assembly
ID Part Number Description
1 4203-367 1 SHOE CONTACT BRASS 3/8” x 3/8” x12-5/8”
2 4215-600 2 BRACKET BRASS U-SHAPE
3 B05-205 4 10-24 x 1/4” SL RD HD M/S
4 3602-150 2 FLAT TWISTED SPRING CONTACT SHOE
5 B10-300 2 1/4-20 LK HEX NUT W/NYLON
6 4215-700 2 SPACER 1/4” x 1/2” FOR CONTACT SHOE
7 3603-075 1 COIL SPRING LH FOR CONTACT SHOE T 2 T 4
8 4215-900 1 BAR ROUND 1/4” x 10” FOR T-2
9 4215-400 1 BRACKET WELDED FOR T2/T4
10 3603-050 1 COIL SPRING RH FOR CONTACT SHOE T 2 T 4
11* 1001-085 20 CANVAS RIBBON 3” x 24” W/PIN
54362
9
10
11
1
7
8
5
6
4
3
2
*
*
= Quantity will vary depending on machine length
