3.0 Transportation, assembly and installation
This part of the Operating Manual is directed to the service personnel and internal authorized
personnel.
3.1 Transportation
3.1.1 Feeder
The folding unit one and the continuous
feeder are delivered in separate crates.
Carry the pallet with a fork lift as close
as possible to its final position.
Unscrew continuous feeder from the
pallet. You should hang tm ropes on the
points 6 and 7 and lift it minimal with the
use of a fork lift. Remove the pallet and
set the continuous feeder to its final
position.
Danger through heavy machines components.
Negligence can cause heavy personal injuries or extensive damages.
If the weight amounts more than 25 kg, a further person must be aid for
taken of the components.
&$87,21
Danger before turn of component during the unloading and
assembling process.
Negligence can cause heavy personal injuries or extensive damages.
• Note the weight statement for the carrier under chapter „technical data“.
• Use the forklift for transportation.
• Arrange additional personnel for unloading and setting up. Some
machine groups must be additionaly secured and supported.
:$51,1*
6
7
