MBO B21 - Edge Trimming

Alterations reserved
Version 05/2008
Operating Manual B21-C - en
Page 77
5.6 Edge trimming
Install the knife holder 2 which has rubber ring 4 and cutting knife 7 onto the upper slitter shaft 3.
You may place a control roller to the second rubber ring as additional guide. Stripper 6 should be
used to guide paper cut-off between rubber ring and counter knife.
2
3
4 5 6
7
