MBO B21 - Drive Belt for Suction Wheel; Drive Belt for Foldrollers and Slitter Shaft at Parallel Unit; Main Drive of Parallel Unit

Alterations reserved
Version 05/2008
Operating Manual B21-C - en
Page 51
4.1.5 Drive belt for suction wheel
The drive belt 2 is tensioned by means of
tensioning lever 1.
4.1.6 Drive belt for foldrollers and slitter shaft at parallel unit
The drive belt 4 is tensioned by means of
tensioning lever 3.
4.1.7 Main drive of parallel unit
The poly-V-belt 5 coming from the main
drive shaft 7 to the parallel unit is
tensioned by means of tensioning
lever 6.
1 2
3
4
7
6
5
