Alterations reserved
Version 05/2008
Operating Manual B21-C - en
Page 47
3.3.2 Main current connection
'$1*(5
Danger, the printed circuit board (p.c.b.) of the stream delivery is
provided with 220 voltages!
Negligence can cause heavy injuries or death.
If you are working on the opened cabinet of the delivery make sure that no
power is supplied or do not touch this p.c.b!
&$87,21
Make sure that power supply and frequency correspond with the data of
your machine! These data should be checked with the label on the side of
the control cabinet.
3.3.3 Stream delivery
&$87,21
Consider Clockwise rotating field! After wiring has been completed the
terminals must be protected with cover plates provided .
'$1*(5
After connections have been completed check the rotating field of motors
as described under item 3.3.1. However, if one of these motors should
have the wrong rotating field, change the connection of the individual motor
at the terminal. Turn OFF the machine immediately, if direction of pile plate
does not correspond with switch position 1.10 at main control panel.
Otherwise the limit switch control will not function properly and switch
OFF! This may cause serious personal injuries or extensive damage to the
feeder !
Insert the cable in the base of the control cabinet and connect it with the main terminals provided
according to the attached wiring diagram.
