Alterations reserved
Version 05/2008
Operating Manual B21-C - en
Page 65
2
1
3
4
2.5 Vacu-Infeed (Option)
The Vacu-Infeed 1 transports
the sheets onto the register table 2.
The power of vacuum for various
types of paper can be adjusted
through the red screw 3,
use scale +/-
Depending on the sheets tendency
to roll the point of suction can be set
forward or backward through lever 4. The
red markings 5 indicate
the position.
