4.1.8 Drive belt for foldrollers at parallel unit and slitter shafts at subsequent unit
See item 4.1.3 page 49.
4.1.9 Drive belt at register table of following folding unit
Danger, overstretching of the drive belt.
Negligence can cause material damage.
Let the folding unit run by turning the hand wheel. At the same time the
cross rollers must be easy to stop with the other hand.
The drive belt 6 should be tensioned by
means of tape tensioner 5.
&$87,21
Danger befor running belt drive.
Danger of injuries to fingers.
This work should be carried out by one person only !
