Alterations reserved
Version 05/2008
Operating Manual B21-C - en
Page 45
3.3 Electrical connection
Danger of electric tension.
Negligence can cause, heavy injuries or death.
Report damaged electrical connections to respnsible supervisor.
'$1*(5
Danger of electric tension at head clams with main switch off.
Negligence can cause, heavy injuries or death.
Work at the electronics can only be carried out of authorized persons or
skilled personnel.
'$1*(5
3.2 Assembly and installation of machine
Carry the machine to its final position.
Plastic feets 3 must be placed
underneath the eight levelling bolts. Level
out the machine by means of these
levelling bolts. Alignments should be
made in crossdirection on the upper, free
accessible foldroller 2.
Levelling should be made also in
longitudinal direction on side frames 1
at left and right side.
Insert the buckle plates. Detach the
guide rails at register table and affix
slitter shafts. All these works are
descriped under the following category
“Operation of the Machine”.
1
2
3
4
1
3
3
