TA80V User Manual
7
- Figure Figure 2-3 TA80V Left-side view
1. Top Cover 2.Pressure Gauge 3. Soda Lime Canister 4. Speaker Port
5. Oxygen sensor interface 6. ETCO2 module interface
7. Flow sensor interface (connected with white pipe)
8. Flow sensor interface (connected to the blue tube, close to the animal patient end)
9. CO2 module adapter
1
5
6
4
3
2
7
8
9
