AVTM246004 BITE 2/2P Rev 4 July 2011
112
5.
Double
-
click Add/Remove Programs.
Select Add/Remove Programs
6.
In
the
Add/Remove Programs Properties
box, click
Install
.
Click
Install
Add/Remove Programs Properties
7.
Click
Next,
then
Finish
to begin installation.
