APPENDIX A: TECHNICAL SPECIFICATIONS
AVTM246004 BITE 2/2P Rev 4 July 2011
93
Fuses
Function Location Type
Primary
Double Pole
J1 Connector Panel T, 2 A, 250 V
5 mm x 20 mm
Secondary
Double Pole
Internal XF1, XF2 ATM 15, 600 V
10.3 mm x 38.1 mm
Leads
Double Pole
Source Leads ATM 15, 600 V
10.3 mm x 38.1 mm
Mechanical
Dimensions
BITE 2
Transmitter
Enclosure
14 x 10.5 x 6.5 in. (L x W x D)
(36 x 27 x 16 cm)
BITE 2P
Transmitter
Enclosure
18.5 x 14.6 x 7.5 in. (L x W x D)
(47 x 37 x 19 cm)
Receiver
Enclosure
7.25 x 11.25 x 2 in. (irregular shape)
BITE 2P instrument includes
standard accessories.
Weight (Total)
BITE 2 Transmitter: 18 lb. (8.2 kg)
BITE 2P Transmitter Only 29 lb. (13 kg)
Receiver: 1.6 lb. (0.72 kg)
Receiver Display
Digital LCD meter, 5 x 7 dot matrix, 2-line z 16 character,
electroluminescent backlighting,
2.19 in. (55.7 mm) x 0.43 in. (11 mm) viewing area,
displays measured parameters in dark numbers on an
electroluminescent background. Contrast adjustable from
menu selection
Commercial temperature and humidity ranges for the
LCD will limit the useful measurement environment.
