APPENDIX A: TECHNICAL SPECIFICATIONS
AVTM246004 BITE 2/2P Rev 4 July 2011
95
Accessories - Standard
• Current source leads (transmitter to battery): two 14
AWG standard copper leads with acid resistant insulation.
Wire rating 600 V dc
Length: 20 ft (3.0 m)
Termination
(transmitter):
4-pin, shrouded
Termination (battery): Bulldog-type Mueller clips
Fuse
(Cat. No. 246003-47):
15 ATM, 600 V (each conductor)
• Current sensor: clamp-on CT with 2-in (50.8 mm) opening.
Wire rating 600 V dc
CT ratio: 1000:1, 4% accuracy
Length: 5 ft (1.5 m)
Termination
(transmitter):
Nonmetallic push lock, 7 pin
Termination (CT): Direct connection
• CT Extension cable: for clamp-on current sensor (CT).
Wire rating 300 V
Length: 6 ft (1.8 m)
Termination: Nonmetalic push lock 7 pin,
both ends
• Accessory bag: for receiver, charger and test leads. (BITE 2)
