M
AVTM246004 BITE 2/2P Rev 4 July 2011
34
For example, suppose that the strap you want to measure
consists of four cables, but you can get the standard CT
around only two of them. You would need to enter a multiplier
of 2.
The receiver would then multiply the reading you take by two
so that the proper test results are computed for all four
cables.
Pressing
increases the
multiplier. Pressing
decreases the multiplier.
2. Press
or
to specify the correct multiplier.
3. When the multiplier you want to use is displayed, press
to accept the multiplier value.
Saving the settings saves the
baseline, warn and fail values
and the multiplier.
The receiver screen asks if you want to save settings
Y SAVE SETTING?
N (Y/N) MENU
Press
(for YES)
or
for (NO). Proceed to Step Six.
