AVTM246004 BITE 2/2P Rev 4 July 2011
76
4. Carefully remove the probe housing. Remove the back
cover.
G
CAUTION
Do not disturb the wrist strap, trigger assembly, or wiring
harness.
5. Locate the battery pack at the base of the receiver.
Unplug the battery pack from the 5-PIN connector of the
receiver printed circuit board
Dispose of the Ni-Cd battery
pack in an environmentally safe
way.
6. Install the replacement battery pack (part number 30654).
Be sure to align the replacement battery pack connector
with the keyed mating connector on the printed circuit
board.
7. Reassemble the receiver by placing the back cover over
the printed circuit board.Ensure that the two connector-
mounting plates are aligned with the channels inside the
back cover.
8. Snap the back cover into place, and then fasten it using
the six Phillips head screws.
9. Snap the probe housing into place, and then fasten it
using the two Phillips head screws.
F
WARNING
Make sure that no wires are pinched when replacing
covers and housings!!!!!
