Megger TM1700 Series User Manual

16 TM1700-SERIES ZP-BL16E BL1448GE
3 SYSTEM OVERVIEW
3
System overview
3.1 The instrument
On front is the control panel where from you can
operate and monitor the circuit breaker position, you
set the operation sequence and run the measurement.
On top is the panel that includes all connectors for in
and outputs.
TM1710
The TM1710 is a “black box” version equipped with
one Control section, one Timing M/R section and one
Digital section.
TM1720
The TM1720 is a “black box” version with two Con-
trol sections, one Timing Aux, one Timing M/R section
and one Digital section.
TM1750
The TM1750 has two Control sections, one Timing
Aux, one Timing M/R section and one Digital section.
