STEP 2: Connect
Second step is to connect the test leads according to
the graphical help screen (Analyzer view).
1] Turn the OPERATE/MEASURE button.
The instrument automatically selects and per-
forms close or open operation depending on
the actual circuit breaker state (Auto-detect
breaker state).
Note Auto-detect breaker state” is the default set-
ting in “System Settings”.
STEP 3: Inspect
The measurement is performed, analysed and the
results will be displayed on the screen. Magnification
and compare functions are available.
Note For more advanced setup there is still the
opportunity to control all the details in the
measurement.
After the test it is possible to print a test report, using
CABAWin on a PC. With CABA Win you can make a
more advanced analysis of the data.
