62 TM1700-SERIES ZP-BL16E BL1448GE
5 PERFORM TESTING
5
Perform testing
5.1 TM1700 Start-up
See section “4.1 Start/Shut down CABA Local” on
page 60 for how to start the instrument.
5.2 Check list - before
testing
IMPORTANT
Always follow the safety regulations in
chapter 1 of this manual.
Always comply with local safety regula-
tions.
Prior testing a breaker check what of the following is
needed and available:
▪
An instrument with a sufficient number of measurement
channels
▪ Transducers — if e.g. contact travel shall be measured
▪ Timing and transducer cables
▪ Mounting accessories for transducers
▪ Accessories for advanced testing applications such as
DRM or vibration
▪ Cables for breaker control and information about how to
connect them to the operating mechanism
The breaker definition must be available in the breaker
list in CABA Local before testing starts or you run a
quick test with definitions from the selected template.
You must either:
A] select a breaker in the list
B] define a new breaker
C] import an existing circuit breaker from CABA
Win.
D] run a quick test
Also make sure that all necessary transducers are
predefined and by that available in the transducer list
of CABA Local.
