7 SPECIFICATIONS
Analog section (none, 1 or 2)
General
No. of channels 3 isolated channels
Time base inaccuracy ±0.01% of reading ±1 sample interval
Max. sample rate 40 kHz
Measurement time 200 s at 10 kHz sample rate
Transducer resistance 500 Ω – 10 kΩ at 10 V output
Output
Voltage output 10 V DC ±5%, 24 V DC ±5%
Max. output current 30 mA
Current measurement
Measurement range ±22 mA
Resolution 16 bits
Inaccuracy ±1% of reading ±0.1% of range
Voltage measurement
Input voltage range 0 – 250 V AC, 0 – 350 V DC
Measurement ranges ±10 V DC, 0 – 250 V AC / DC
Resolution 16 bits
Inaccuracy
250 V range ±1% of reading ±0.1% of range
10 V range ±0.1% of reading ±0.01% of range
Digital section
General
No. of channels 6
Supported types Incremental transducers, RS422
Time base inaccuracy ±0.01% of reading ±1 sample interval
Max. sample rate 40 kHz
Measurement time 200 s at 10 kHz sample rate
Output
Voltage 5 V DC ±5% or 12 V DC ±5%
Max. output current 700 mA
Digital input
Range ±32000 pulses
Resolution 1 pulse
Inaccuracy ±1 pulse
Timing Aux section
General
No. of channels 6 isolated channels
Time base inaccuracy ±0.01% of reading ±1 sample interval
Max. sample rate 40 kHz
Measurement time 200 s at 10 kHz sample rate
Voltage Mode
Input voltage range 0 – 250 V AC, 0 – 350 V DC
Status threshold ±10 V
Inaccuracy ±0.5 V
Contact mode
Open circuit voltage 25 – 35 V DC
Short circuit current 10 – 30 mA DC
Status threshold Closed < 100 Ω, Open > 2 kΩ
DCM module (Optional)
General
No. of channels 6
Weight 0.6 kg (1.4 lbs)
Output
Voltage 0 - 5 V rms AC
Current 0 - 70 mA rms AC

Megger TM1700 Series Specifications

General

Brand	Megger
Model	TM1700 Series
Category	Measuring Instruments
Language	English
