Document reference MAMPS-HW/E HARDWARE MANUAL
Edition 18 - March 2022 VM600 machinery protection system (MPS)
9-3
Definition of screw terminals on the IOC4T card
CONFIGURATION OF MPC4 / IOC4T CARDS
9RAW1H
High line of differential output corresponding to the raw signal for
measurement channel 1
10 RAW 1L
Low line of differential output corresponding to the raw signal for
measurement channel 1
11 RAW 2H
High line of differential output corresponding to the raw signal for
measurement channel 2
12 RAW 2L
Low line of differential output corresponding to the raw signal for
measurement channel 2
13 RAW 3H
High line of differential output corresponding to the raw signal for
measurement channel 3
14 RAW 3L
Low line of differential output corresponding to the raw signal for
measurement channel 3
15 RAW 4H
High line of differential output corresponding to the raw signal for
measurement channel 4
16 RAW 4L
Low line of differential output corresponding to the raw signal for
measurement channel 4
Table 9-1: Definition of terminals for J1, J2 and J3 on the IOC4T card (continued)
Terminal Name Definition
