HARDWARE MANUAL Document reference MAMPS-HW/E
VM600 machinery protection system (MPS) Edition 18 - March 2022
C-2
DEFINITION OF BACKPLANE CONNECTOR PINS
Figure C-1: Pin definitions for slot 0
SLOT 0 SLOT 0
CONNECTOR P1 CONNECTOR P3
PIN No. ROW A ROW B ROW C PIN No. ROW A ROW B ROW C
1 D00 BBSY* D08 1 Conn. P1, Z1 Not connected Conn. P1, D1
2 D01 BCLR* D09 2 Conn. P1, Z2 Not connected Conn. P1, D2
3 D02 ACFAIL* D10 3 Conn. P1, Z3 Not connected Conn. P1, D3
4 D03 BG0IN* D11 4 Conn. P1, Z4 Not connected Conn. P1, D4
5 D04 BG0OUT* D12 5 Conn. P1, Z5 Not connected Conn. P1, D5
6 D05 BG1IN* D13 6 Conn. P1, Z6 Not connected Conn. P1, D6
7 D06 BG1OUT* D14 7 Conn. P1, Z7 Not connected Conn. P1, D7
8 D07 BG2IN* D15 8 Conn. P1, Z8 Not connected Conn. P1, D8
9 GND BG2OUT* GND 9 Conn. P1, Z9 Not connected Conn. P1, D9
10 SYSCLK BG3IN* SYSFAIL* 10 Conn. P1, Z10 Not connected Conn. P1, D10
11 GND BG3OUT* BERR* 11 Conn. P1, Z11 Not connected Conn. P1, D11
12 DS1* BR0* SYSRESET* 12 Conn. P1, Z12 Not connected Conn. P1, D12
13 DS0* BR1* LWORD* 13 Conn. P1, Z13 Not connected Conn. P1, D13
14 WRITE* BR2* AM5 14 Conn. P1, Z14 Not connected Conn. P1, D14
15 GND BR3* A23 15 Conn. P1, Z15 Not connected Conn. P1, D15
16 DTACK* AM0 A22 16 Conn. P1, Z16 Not connected Conn. P1, D16
17 GND AM1 A21 17 Conn. P1, Z17 Not connected Conn. P1, D17
18 AS* AM2 A20 18 Conn. P1, Z18 Not connected Conn. P1, D18
19 GND AM3 A19 19 Conn. P1, Z19 Not connected Conn. P1, D19
20 IACK* GND A18 20 Conn. P1, Z20 Not connected Conn. P1, D20
21 IACKIN* Not connected A17 21 Conn. P1, Z21 Not connected Conn. P1, D21
22 IACKOUT* Not connected A16 22 Conn. P1, Z22 Not connected Conn. P1, D22
23 AM4 GND A15 23 Conn. P1, Z23 Not connected Conn. P1, D23
24 A07 IRQ7* A14 24 Conn. P1, Z24 Not connected Conn. P1, D24
25 A06 IRQ6* A13 25 Conn. P1, Z25 Not connected Conn. P1, D25
26 A05 IRQ5* A12 26 Conn. P1, Z26 Not connected Conn. P1, D26
27 A04 IRQ4* A11 27 Conn. P1, Z27 Not connected Conn. P1, D27
28 A03 IRQ3* A10 28 Conn. P1, Z28 Not connected Conn. P1, D28
29 A02 IRQ2* A9 29 Conn. P1, Z29 Not connected Conn. P1, D29
30 A01 IRQ1* A8 30 Conn. P1, Z30 Not connected Conn. P1, D30
31 -12 V +5 V STDBY +12 V 31 Conn. P1, Z31 Not connected Conn. P1, D31
32 +5 V +5 V +5 V 32 Conn. P1, Z32 Not connected Conn. P1, D32
SLOT 0 SLOT 0
CONNECTOR P2 CONNECTOR P4
PIN No. ROW A ROW B ROW C PIN No. ROW A ROW B ROW C
1 Not connected +5 V Not connected 1 Conn.. P2, Z1 Not connected Conn. P2, D1
2 Not connected GND Not connected 2 Conn. P2, Z2 Not connected Conn. P2, D2
3 Not connected RESERVED Not connected 3 Conn. P2, Z3 Not connected Conn. P2, D3
4 Not connected A24 Not connected 4 Conn. P2, Z4 Not connected Conn. P2, D4
5 Not connected A25 Not connected 5 Conn. P2, Z5 Not connected Conn. P2, D5
6 Not connected A26 Not connected 6 Conn. P2, Z6 Not connected Conn. P2, D6
7 Not connected A27 Not connected 7 Conn. P2, Z7 Not connected Conn. P2, D7
8 Not connected A28 Not connected 8 Conn. P2, Z8 Not connected Conn. P2, D8
9 Not connected A29 Not connected 9 Conn. P2, Z9 Not connected Conn. P2, D9
10 Not connected A30 Not connected 10 Conn. P2, Z10 Not connected Conn. P2, D10
11 Not connected A31 Not connected 11 Conn. P2, Z11 Not connected Conn. P2, D11
12 Not connected GND Not connected 12 Conn. P2, Z12 Not connected Conn. P2, D12
13 Not connected +5 V Not connected 13 Conn. P2, Z13 Not connected Conn. P2, D13
14 Not connected D16 Not connected 14 Conn. P2, Z14 Not connected Conn. P2, D14
15 Not connected D17 Not connected 15 Conn. P2, Z15 Not connected Conn. P2, D15
16 Not connected D18 Not connected 16 Conn. P2, Z16 Not connected Conn. P2, D16
17 Not connected D19 Not connected 17 Conn. P2, Z17 Not connected Conn. P2, D17
18 Not connected D20 Not connected 18 Conn. P2, Z18 Not connected Conn. P2, D18
19 Not connected D21 Not connected 19 Conn. P2, Z19 Not connected Conn. P2, D19
20 Not connected D22 Not connected 20 Conn. P2, Z20 Not connected Conn. P2, D20
21 Not connected D23 Not connected 21 Conn. P2, Z21 Not connected Conn. P2, D21
22 Not connected GND Not connected 22 Conn. P2, Z22 Not connected Conn. P2, D22
23 Not connected D24 Not connected 23 Conn. P2, Z23 Not connected Conn. P2, D23
24 Not connected D25 Not connected 24 Conn. P2, Z24 Not connected Conn. P2, D24
25 Not connected D26 Not connected 25 Conn. P2, Z25 Not connected Conn. P2, D25
26 Not connected D27 Not connected 26 Conn. P2, Z26 Not connected Conn. P2, D26
27 Not connected D28 Not connected 27 Conn. P2, Z27 Not connected Conn. P2, D27
28 Not connected D29 Not connected 28 Conn. P2, Z28 Not connected Conn. P2, D28
29 Not connected D30 Not connected 29 Conn. P2, Z29 Not connected Conn. P2, D29
30 Not connected D31 Not connected 30 Conn. P2, Z30 Not connected Conn. P2, D30
31 Not connected GND Not connected 31 Conn. P2, Z31 Not connected Conn. P2, D31
32 Not connected +5 V Not connected 32 Conn. P2, Z32 Not connected Conn. P2, D32
