SLOTS 1-2 SLOTS 1-2
CONNECTOR P1 CONNECTOR P3
PIN No. ROW A ROW B ROW C PIN No. ROW A ROW B ROW C
1 D00 BBSY* D08 1 OC 0 TACHO 0 OC 8
2 D01 BCLR* D09 2 OC 1 TACHO 1 OC 9
3 D02 ACFAIL* D10 3 OC 2 TACHO 2 OC 10
4 D03 BG0IN* D11 4 OC 3 TACHO 3 OC 11
5 D04 BG0OUT* D12 5 OC 4 TACHO 4 OC 12
6 D05 BG1IN* D13 6 OC 5 TACHO 5 OC 13
7 D06 BG1OUT* D14 7 OC 6 TACHO 6 OC 14
8 D07 BG2IN* D15 8 OC 7 TACHO 7 OC 15
9 GND BG2OUT* GND 9 GND TACHO GND RAW_H 2
10 SYSCLK BG3IN* SYSFAIL* 10 RAW_H 0 RAW_H 1 RAW_L 2
11 GND BG3OUT* BERR* 11 RAW_L 0 RAW_L 1 RAW_H 5
12 DS1* BR0* SYSRESET* 12 RAW_H 3 RAW_H 4 RAW_L 5
13 DS0* BR1* LWORD* 13 RAW_L 3 RAW_L 4 RAW_H 8
14 WRITE* BR2* AM5 14 RAW_H 6 RAW_H 7 RAW_L 8
15 GND BR3* A23 15 RAW_L 6 RAW_L 7 RAW_H 11
16 DTACK* AM0 A22 16 RAW_H 9 RAW_H 10 RAW_L 11
17 GND AM1 A21 17 RAW_L 9 RAW_L 10 RAW_H 14
18 AS* AM2 A20 18 RAW_H 12 RAW_H 13 RAW_L 14
19 GND AM3 A19 19 RAW_L 12 RAW_L 13 RAW_H 17
20 IACK* GND A18 20 RAW_H 15 RAW_H 16 RAW_L 17
21 IACKIN* Not connected A17 21 RAW_L 15 RAW_L 16 RAW_H 20
22 IACKOUT* Not connected A16 22 RAW_H 18 RAW_H 19 RAW_L 20
23 AM4 GND A15 23 RAW_L 18 RAW_L 19 RAW_H 23
24 A07 IRQ7* A14 24 RAW_H 21 RAW_H 22 RAW_L 23
25 A06 IRQ6* A13 25 RAW_L 21 RAW_L 22 RAW_H 26
26 A05 IRQ5* A12 26 RAW_H 24 RAW_H 25 RAW_L 26
27 A04 IRQ4* A11 27 RAW_L 24 RAW_L 25 RAW_H 29
28 A03 IRQ3* A10 28 RAW_H 27 RAW_H 28 RAW_L 29
29 A02 IRQ2* A9 29 RAW_L 27 RAW_L 28 RAW_H 31
30 A01 IRQ1* A8 30 GND RAW_H 30 RAW_L 31
31 -12 V +5 V STDBY +12 V 31 -12 V RAW_L 30 +12 V
32 +5 V +5 V +5 V 32 +5 V +5 V +5 V
SLOTS 1-2 SLOTS 1-2
CONNECTOR P2 CONNECTOR P4
PIN No. ROW A ROW B ROW C PIN No. ROW A ROW B ROW C
1 Not connected +5 V Not connected 1 Not connected Not connected Not connected
2 Not connected GND Not connected 2 Not connected Not connected Not connected
3 Not connected RESERVED Not connected 3 Not connected Not connected Not connected
4 Not connected A24 Not connected 4 Not connected Not connected Not connected
5 Not connected A25 Not connected 5 Not connected Not connected Not connected
6 Not connected A26 Not connected 6 Not connected Not connected Not connected
7 Not connected A27 Not connected 7 Not connected Not connected Not connected
8 Not connected A28 Not connected 8 Not connected Not connected Not connected
9 Not connected A29 Not connected 9 Not connected Not connected Not connected
10 Not connected A30 Not connected 10 Not connected Not connected Not connected
11 Not connected A31 Not connected 11 Not connected Not connected Not connected
12 Not connected GND Not connected 12 Not connected Not connected Not connected
13 Not connected +5 V Not connected 13 Not connected Not connected Not connected
14 Not connected D16 Not connected 14 Not connected Not connected Not connected
15 Not connected D17 Not connected 15 Not connected Not connected Not connected
16 Not connected D18 Not connected 16 Not connected Not connected Not connected
17 Not connected D19 Not connected 17 Not connected Not connected Not connected
18 Not connected D20 Not connected 18 Not connected Not connected Not connected
19 Not connected D21 Not connected 19 Not connected Not connected Not connected
20 Not connected D22 Not connected 20 Not connected Not connected Not connected
21 Not connected D23 Not connected 21 Not connected Not connected Not connected
22 Not connected GND Not connected 22 Not connected Not connected Not connected
23 Not connected D24 Not connected 23 Not connected Not connected Not connected
24 Not connected D25 Not connected 24 Not connected Not connected Not connected
25 Not connected D26 Not connected 25 Not connected Not connected Not connected
26 Not connected D27 Not connected 26 Not connected Not connected Not connected
27 Not connected D28 Not connected 27 Not connected Not connected Not connected
28 Not connected D29 Not connected 28 Not connected Not connected Not connected
29 Not connected D30 Not connected 29 Not connected Not connected Not connected
30 Not connected D31 Not connected 30 Not connected Not connected Not connected
31 Not connected GND Not connected 31 Not connected Not connected Not connected
32 Not connected +5 V Not connected 32 Not connected Not connected Not connected
