DEFINITION OF BACKPLANE CONNECTOR PINS
Figure C-3: Pin definitions for slots 3 to 14
SLOTS 3-14 SLOTS 3-14
CONNECTOR P1 CONNECTOR P3
PIN No. ROW A ROW B ROW C PIN No. ROW A ROW B ROW C
1 D00 BBSY* D08 1 OCx 0 TACHO 0 OCx 8
2 D01 BCLR* D09 2 OCx 1 TACHO 1 OCx 9
3 D02 ACFAIL* D10 3 OCx 2 TACHO 2 OCx 10
4 D03 BG0IN* D11 4 OCx 3 TACHO 3 OCx 11
5 D04 BG0OUT* D12 5 OCx 4 TACHO 4 OCx 12
6 D05 BG1IN* D13 6 OCx 5 TACHO 5 OCx 13
7 D06 BG1OUT* D14 7 OCx 6 TACHO 6 OCx 14
8 D07 BG2IN* D15 8 OCx 7 TACHO 7 OCx 15
9 GND BG2OUT* GND 9 GND TACHO GND RAW_H 2
10 SYSCLK BG3IN* SYSFAIL* 10 RAW_H 0 RAW_H 1 RAW_L 2
11 GND BG3OUT* BERR* 11 RAW_L 0 RAW_L 1 RAW_H 5
12 DS1* BR0* SYSRESET* 12 RAW_H 3 RAW_H 4 RAW_L 5
13 DS0* BR1* LWORD* 13 RAW_L 3 RAW_L 4 RAW_H 8
14 WRITE* BR2* AM5 14 RAW_H 6 RAW_H 7 RAW_L 8
15 GND BR3* A23 15 RAW_L 6 RAW_L 7 RAW_H 11
16 DTACK* AM0 A22 16 RAW_H 9 RAW_H 10 RAW_L 11
17 GND AM1 A21 17 RAW_L 9 RAW_L 10 RAW_H 14
18 AS* AM2 A20 18 RAW_H 12 RAW_H 13 RAW_L 14
19 GND AM3 A19 19 RAW_L 12 RAW_L 13 RAW_H 17
20 IACK* GND A18 20 RAW_H 15 RAW_H 16 RAW_L 17
21 IACKIN* Not connected A17 21 RAW_L 15 RAW_L 16 RAW_H 20
22 IACKOUT* Not connected A16 22 RAW_H 18 RAW_H 19 RAW_L 20
23 AM4 GND A15 23 RAW_L 18 RAW_L 19 RAW_H 23
24 A07 IRQ7* A14 24 RAW_H 21 RAW_H 22 RAW_L 23
25 A06 IRQ6* A13 25 RAW_L 21 RAW_L 22 RAW_H 26
26 A05 IRQ5* A12 26 RAW_H 24 RAW_H 25 RAW_L 26
27 A04 IRQ4* A11 27 RAW_L 24 RAW_L 25 RAW_H 29
28 A03 IRQ3* A10 28 RAW_H 27 RAW_H 28 RAW_L 29
29 A02 IRQ2* A9 29 RAW_L 27 RAW_L 28 RAW_H 31
30 A01 IRQ1* A8 30 GND RAW_H 30 RAW_L 31
31 -12 V +5 V STDBY +12 V 31 -12 V RAW_L 30 +12 V
32 +5 V +5 V +5 V 32 +5 V +5 V +5 V
SLOTS 3-14 SLOTS 3-14
CONNECTOR P2 CONNECTOR P4
PIN No. ROW A ROW B ROW C PIN No. ROW A ROW B ROW C
1 Conn. P4, A1 Conn. P4, B1 Conn. P4, C1 1 Conn. P2, A1 Conn. P2, B1 Conn. P2, C1
2 Conn. P4, A2 Conn. P4, B2 Conn. P4, C2 2 Conn. P2, A2 Conn. P2, B2 Conn. P2, C2
3 Conn. P4, A3 Conn. P4, B3 Conn. P4, C3 3 Conn. P2, A3 Conn. P2, B3 Conn. P2, C3
4 Conn. P4, A4 Conn. P4, B4 Conn. P4, C4 4 Conn. P2, A4 Conn. P2, B4 Conn. P2, C4
5 Conn. P4, A5 Conn. P4, B5 Conn. P4, C5 5 Conn. P2, A5 Conn. P2, B5 Conn. P2, C5
6 Conn. P4, A6 Conn. P4, B6 Conn. P4, C6 6 Conn. P2, A6 Conn. P2, B6 Conn. P2, C6
7 Conn. P4, A7 Conn. P4, B7 Conn. P4, C7 7 Conn. P2, A7 Conn. P2, B7 Conn. P2, C7
8 Conn. P4, A8 Conn. P4, B8 Conn. P4, C8 8 Conn. P2, A8 Conn. P2, B8 Conn. P2, C8
9 Conn. P4, A9 Conn. P4, B9 Conn. P4, C9 9 Conn. P2, A9 Conn. P2, B9 Conn. P2, C9
10 Conn. P4, A10 Conn. P4, B10 Conn. P4, C10 10 Conn. P2, A10 Conn. P2, B10 Conn. P2, C10
11 Conn. P4, A11 Conn. P4, B11 Conn. P4, C11 11 Conn. P2, A11 Conn. P2, B11 Conn. P2, C11
12 Conn. P4, A12 Conn. P4, B12 Conn. P4, C12 12 Conn. P2, A12 Conn. P2, B12 Conn. P2, C12
13 Conn. P4, A13 Conn. P4, B13 Conn. P4, C13 13 Conn. P2, A13 Conn. P2, B13 Conn. P2, C13
14 Conn. P4, A14 Conn. P4, B14 Conn. P4, C14 14 Conn. P2, A14 Conn. P2, B14 Conn. P2, C14
15 Conn. P4, A15 Conn. P4, B15 Conn. P4, C15 15 Conn. P2, A15 Conn. P2, B15 Conn. P2, C15
16 Conn. P4, A16 Conn. P4, B16 Conn. P4, C16 16 Conn. P2, A16 Conn. P2, B16 Conn. P2, C16
17 Conn. P4, A17 Conn. P4, B17 Conn. P4, C17 17 Conn. P2, A17 Conn. P2, B17 Conn. P2, C17
18 Conn. P4, A18 Conn. P4, B18 Conn. P4, C18 18 Conn. P2, A18 Conn. P2, B18 Conn. P2, C18
19 Conn. P4, A19 Conn. P4, B19 Conn. P4, C19 19 Conn. P2, A19 Conn. P2, B19 Conn. P2, C19
20 Conn. P4, A20 Conn. P4, B20 Conn. P4, C20 20 Conn. P2, A20 Conn. P2, B20 Conn. P2, C20
21 Conn. P4, A21 Conn. P4, B21 Conn. P4, C21 21 Conn. P2, A21 Conn. P2, B21 Conn. P2, C21
22 Conn. P4, A22 Conn. P4, B22 Conn. P4, C22 22 Conn. P2, A22 Conn. P2, B22 Conn. P2, C22
23 Conn. P4, A23 Conn. P4, B23 Conn. P4, C23 23 Conn. P2, A23 Conn. P2, B23 Conn. P2, C23
24 Conn. P4, A24 Conn. P4, B24 Conn. P4, C24 24 Conn. P2, A24 Conn. P2, B24 Conn. P2, C24
25 Conn. P4, A25 Conn. P4, B25 Conn. P4, C25 25 Conn. P2, A25 Conn. P2, B25 Conn. P2, C25
26 Conn. P4, A26 Conn. P4, B26 Conn. P4, C26 26 Conn. P2, A26 Conn. P2, B26 Conn. P2, C26
27 Conn. P4, A27 Conn. P4, B27 Conn. P4, C27 27 Conn. P2, A27 Conn. P2, B27 Conn. P2, C27
28 Conn. P4, A28 Conn. P4, B28 Conn. P4, C28 28 Conn. P2, A28 Conn. P2, B28 Conn. P2, C28
29 Conn. P4, A29 Conn. P4, B29 Conn. P4, C29 29 Conn. P2, A29 Conn. P2, B29 Conn. P2, C29
30 Conn. P4, A30 Conn. P4, B30 Conn. P4, C30 30 Conn. P2, A30 Conn. P2, B30 Conn. P2, C30
31 Conn. P4, A31 Conn. P4, B31 Conn. P4, C31 31 Conn. P2, A31 Conn. P2, B31 Conn. P2, C31
32 Conn. P4, A32 Conn. P4, B32 Conn. P4, C32 32 Conn. P2, A32 Conn. P2, B32 Conn. P2, C32
