SECTION - 2 BOAT CONSTRUCTION
90-899883183 DECEMBER 2007 Page 3 / 4
Engine Bed
Description Measurement
Difference between starboard and port engine mount 57.2 cm (22‑1/2 in.)
Mount adjustment up and down (minimum) 6 mm (1/4 in.)
NOTE: Although the engine mounts allow some adjustment, it is a good practice to ensure that
the front and rear mount locations in the vessel are parallel and in the same plane. This may be
checked by tying a string from the left front mount location to the right rear mount location and
another from right front to left rear. The strings should touch where they cross.
