CHARGING & STARTING SYSTEM
90-855347R1 JANUARY 1999 Page 2B-33
2. If removed, reinstall parts on armature shaft. Use a new locknut and tighten securely
on end of shaft.
11658
e
f
g
d
c
b
a
a
b
c
e
d
f
g
a-Locknut
b-Spacer
c-Spring
d-Drive Assembly
e-Drive End Cap
f-Armature Shaft
g-Washer
3. Lubricate helix threads on armature shaft with a drop of SAE 10W oil.
4. Lubricate bushing in drive end plate with a drop of SAE 10W oil.
5. Position armature into starter frame.
6. Lubricate bushing (located in commutator end cap) with one drop of SAE 10W oil. DO
NOT overlubricate.
7. To prevent damage to brushes and springs when installing commutator end cap, it is
recommended that a brush retaining tool be made as shown:
5″
9/16″
2-1/6″
1-3/4″
a
a
(14.3 mm)
(55.1 mm)
(44.5 mm)
(127.0 mm)
a-Bushing (DO NOT overlubricate)
To Next Page
