OUTBOARD MOTOR INSTALLATION
Page 1D-14 90-855347R1 JANUARY 1999
2. Fasten clamp together with two screws.
a
a-Screws
Filling Fuel System
NOTE: For initial start of a new engine or for an engine that ran out of fuel, or was drained
of fuel, the fuel system should to be filled as follows:
•
Squeeze the fuel line primer bulb until it feels firm.
•
Turn the ignition key switch to the ON position for three seconds. This operates the
electric fuel pump.
•
Turn the ignition key switch back to the OFF position, and squeeze the primer bulb
again until it feels firm. Turn the ignition key switch to the “ON” position again for three
seconds. Continue this procedure until the fuel line primer bulb stays firm.
Oil Injection Set-Up
Filling
1. Fill remote oil tank with the recommended oil listed in the Operation and Maintenance
Manual. Tighten fill cap.
a
a-Fill Cap
