DIRECT FUEL INJECTION

90-855347R1 JANUARY 1999 Page 3B-9

Air Handler Components

REF.

TORQUE

REF

NO.

QTY. DESCRIPTION lb-in lb-ft Nm.

– 1 AIR HANDLER

1 1 ADAPTOR PLATE KIT

2 1 GASKET

3 1 GASKET

4 6 REED BLOCK

5 12 SCREW (1/4-20 x .88) 100 11.5

6 1 OIL PUMP

7 1 GASKET

8 1 BRACKET

9 3 FITTING

10 3 FITTING

11 1 ELBOW

12 1 FITTING (STRAIGHT)

13 6 BUSHING

14 6 GROMMET

15 6 SCREW 140 12 16

16 6 WASHER

17 1 AIR PLENUM KIT

18 1 ELBOW

1 ELBOW (.236 O.D.)

1 ELBOW (.159 O.D.)

20 1 GASKET

21 1 TEMPERATURE SENSOR

22 3 SCREW Drive Tight

23 3 LOCKWASHER

24 12 SCREW (M4 x 16) Drive Tight

25 1 THROTTLE BODY KIT

26 1 O RING

27 4 SCREW 100 11.5
