Mercury Optimax 115 User Manual

DIRECT FUEL INJECTION
90-855347R1 JANUARY 1999 Page 3B-11
Vapor Separator Components
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 1 COVER KIT
2 1 FITTING - Straight
3 1 ELBOW
4 1 SEAL
5 1 FITTING KIT-Pump Outlet
6 1 O RING
7 7 SCREW 30 3.5
8 1 GASKET
9 1 FLOAT KIT
10 1 FLOAT PIN
11 1 NEEDLE VALVE
12 1 SCREW 10 1.0
13 1 FUEL PUMP KIT
14 1 SLEEVE
15 1 BOWL KIT
16 1 SEAL
17 1 PLUG KIT
18 2 ELBOW
19 1 FUEL FILTER ASSEMBLY
20 1 PROBE
