DIRECT FUEL INJECTION
90-855347R1 JANUARY 1999 Page 3B-13
Fuel Rails/Air Compressor Hose Routing
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 1
AIR COMPRESSOR
(See breakdown on Air Compressor Components)
2 5 SCREW (M6 x 12) 100 11.5
3 1 PULLEY
4 2 SCREW 40 54
5 1 HOSE
6 1 INSULATOR SLEEVE (16 IN.)
7 1 FUEL RAIL (STARBOARD)
8 6 INJECTOR
9 4 CLAMP
10 2 HOSE (16 IN.)
11 1 STUD
12 2 WASHER
13 1 NUT 25 34
14 8 STA STRAP
15 1 FUEL RAIL (PORT)
16 1 TUBING (22-1/2 IN.)
17 1 CHECK VALVE
18 1 TUBING (2-1/2 IN.)
19 1 TUBING (28-1/2 IN.)
20 2 CLAMP
21 1 TUBING (28-1/2 IN.)
22 4 SCREW (M5 x 10)
23 4 CLAMP
24 4 STUD
25 4 NUT 33 45
26 1 HOSE (30 IN.) (W/INSULATING SLEEVE)
27 1 HOSE (W/INSULATING SLEEVE)
28 6 CUPPED WASHER
29 4 CLAMP
30 1 INSULATOR SLEEVE (18 IN.)

Mercury Optimax 115 Specifications

General

Fuel Induction System	2-stage Direct Fuel Injection (DFI)
Alternator Amp	60 amp / 756 watt
Steering	Remote
Cylinders	3
Starting	Electric
Displacement	1.5 L
Bore x Stroke	89 x 76 mm
Shaft Length	20" (508 mm)
Horsepower	115 HP
