Mercury Optimax 115 User Manual

6
A
RIGHT HAND NON-RATCHETING
90-855347R1 JANUARY 1999 Page 6A-1
LOWER UNIT
Section 6A – Right Hand Non-Ratcheting
Table of Contents
Gear Housing Specifications (Standard Rotation) 6A-1.
Special Tools 6A-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Notes: 6A-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gear Housing (Drive Shaft)(Standard Rotation) 6A-6. .
Gear Housing (Prop Shaft)(Standard Rotation) 6A-8. . .
General Service Recommendations 6A-10. . . . . . . . . . .
Removal, Disassembly, Cleaning and Inspection
– Standard Rotation 6A-11. . . . . . . . . . . . . . . . . . . . . . . . .
Removal 6A-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Draining and Inspecting Gear Housing
Lubricant 6A-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Water Pump 6A-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bearing Carrier and Propeller Shaft Removal 6A-16.
Shift Shaft 6A-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Propeller Shaft 6A-20. . . . . . . . . . . . . . . . . . . . . . . . . . .
Clutch Actuator Rod 6A-22. . . . . . . . . . . . . . . . . . . . . .
Pinion Gear and Driveshaft 6A-22. . . . . . . . . . . . . . . .
Forward Gear 6A-25. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gear Housing 6A-26. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reassembly and Installation Standard Rotation 6A-26.
Driveshaft Needle Bearing 6A-26. . . . . . . . . . . . . . . . .
Bearing Carrier 6A-27. . . . . . . . . . . . . . . . . . . . . . . . . . .
Forward Gear 6A-30. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Forward Gear Bearing Race 6A-31. . . . . . . . . . . . . . .
Driveshaft and Pinion Gear 6A-32. . . . . . . . . . . . . . . .
Pinion Gear Depth/Forward Gear
Backlash/Reverse Gear Backlash 6A-34. . . . . . . . . .
Clutch Actuator Rod 6A-38. . . . . . . . . . . . . . . . . . . . . .
Shift Shaft Bushing 6A-38. . . . . . . . . . . . . . . . . . . . . . .
Propeller Shaft 6A-39. . . . . . . . . . . . . . . . . . . . . . . . . . .
Water Pump 6A-42. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gear Lubricant Filling Instructions 6A-45. . . . . . . . . .
Installing Gear Housing to Driveshaft Housing 6A-45
Propeller Installation 6A-46. . . . . . . . . . . . . . . . . . . . . .
Gear Housing Specifications (Standard Rotation)
Ratio Pinion Depth
Forward Gear
Backlash
Reverse Gear
Backlash
1.87:1
0.025 in. (0.635 mm)
With Tool 91-12349A2
using Disc #2 and
Flat #7
0.018 in. to 0.027 in.
(0.460 mm to 0.686
mm) Pointer on line
mark #1
0.030 in. to 0.050 in.
(0.762 mm to 1.27 mm)
2.0:1
0.025 in. (0.635 mm)
With Tool 91-12349A2
using Disc #2 and
Flat #7
0.015 in. to 0.022 in.
(0.38 mm to 0.56 mm)
Pointer on line mark
#2
0.030 in. to 0.050 in.
(0.762 mm to 1.27 mm)
2.3:1
0.025 in. (0.635 mm)
With Tool 91-12349A2
using Disc #2 and
Flat #7
0.018 in. to 0.023 in.
(0.46 mm to 0.58 mm)
Pointer on line mark
#4
0.030 in. to 0.050 in.
(0.762 mm to 1.27 mm)
Gearcase Lubricant Capacity
All Ratios 22.5 fl. oz. (665.4 ml)
