IGNITION
90-855347R1 JANUARY 1999 Page 2A-5
Electrical Components
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1
1 ELECTRICAL MOUNTING PLATE
2
6 IGNITION COIL
3
1 HI-TENSION CABLE
4
6 SPARK PLUG (HEAVY DUTY) 240 20 27
5
6 SPACER
6
6 SCREW (1/4-20 x 3-1/4 IN.)
7
1 MAP SENSOR
8
2 SCREW (M6 x 14) 35 4
9
1 TUBING (31 IN.)
10
4 SCREW (.312-18 x 1-1/4 IN.) 235 19.6 26.5
11
4 WASHER
12
4 GROMMET
13
4 BUSHING
14
2 SCREW-engine harness ground (M6 x 14) 35 4
15
6 WASHER
16
6 NUT
17
1 TRIM HARNESS
18
3 RELAY
19
3 DECAL-Trim Relay
20
3 BRACKET
21
3 BUSHING
22
3 GROMMET
23
2 SCREW (M6 x 25) 35 4
24
1 SCREW (M6 x 35) 35 4
25
1 BUSHING
26
2 STA STRAP
27
1 ENGINE HARNESS
28
1 HARNESS (SERVICE ITEM)
29
4 FUSE
30
1 BRACKET-Fuse Holder
31
2 SCREW (M4 x 8)
32
1 ECU (135)
33
1 ECU (150)
34
1 PAD
35
3 SCREW (M6 x 25) 70 8
36
6 BUSHING
37
3 GROMMET
38
2 SCREW (M6 x 14) 100 11.5
39
1 CLIP
40
1 CLAMP
41
2 SCREW (10-16 x 3/8 IN.)
42
1 SOLENOID MOUNTING PLATE
43
3 SCREW (M6 x 12) 150 17
44
2 SCREW (M6 x 14) 35 4
45
1 STARTER SOLENOID
46
2 GROMMET
47
2 SCREW (M6 x 25) 35 4
48
1 CABLE (BLACK)
49
2 BUSHING
50
1 BATTERY CABLE (POSITIVE)
51
2 LOCKWASHER
52
2 NUT (5/16-18) 50 5.5
53
2 NUT (10-32) 8 0.9
54
1 CABLE
55
1 CAP NUT
