8 - ATTACHMENTS AND OPTIONAL EXTRA
8 - 9
• 4X1 BUCKET (800 l) - (1000 l) - (1250 l)
Assemble the attachment on the carriage as described in the paragraph
INSTALLATION OF QUICK-COUPLING ATTACHMENTS in this chapter and use
it with the auxiliary controls in the cab as described in the paragraph CONTROL
OF HYDRAULICALLY FUNCTIONING ATTACHMENTS.
- Weight: (A0800) = 680 kg; (A0820) = 710 kg; (A0870) = 750 kg
- Max capacity: (A0800) = 800 l; (A0820) = 1000 l; (A0870) = 1250 l
TRANSPORT: Circulation on public roads with the bucket connected is only
allowed if the appropriate protection, included with the attachment, is applied.
WARNING! (BUCKET, 4 X 1 BUCKET): the excavation or loading of
loose material using the machine with extended boom, may cause serious
damage to the boom itself; MERLO S.p.A. strongly recommends not to
perform such operation and will not be held responsible for any damage
arising from this use.
