8 - ATTACHMENTS AND OPTIONAL EXTRA
8 - 12
• FLY-JIB WITH WINCH
Light weight trestle structure, highly rigid under load. A shape bent forward
permits to reach an operating height as high as that of the machine combined
with the jib height, keeping the hook clear of the machine. High-resistance anti-
spin rope complete with pulley and rope guide at the jib end (A1300). The winch
is equipped with block valves and descent control valves as well as hook ascent
and descent limiting devices.
Block with safety hook slewing over 360°.
• (P37.12 PLUS - P38.12 PLUS - P38.13 PLUS - P38.14 PLUS - P40.9 PLUS –
P40.17 PLUS – P38.12 – P38.13 – P38.14 – P40.17 – P38.13EE – P40.17EE)
(A1300A)
A = 3520 mm; Weight: 215 kg; Attachment capacity: 600kg
(A1310A)
A = 1900 mm; Weight: 240 kg; Attachment capacity: 1500 kg
(A1215)
A = 1500 mm; Weight: 200 kg; Attachment capacity: 2000 kg
For attachment assembly, operating and maintenance instructions, refer to the
relevant manual.
• (P60.10 - P72.10 – P60.10EE – P72.10EE)
(A1320B)
A = 4010 mm; Weight: 265 kg; Attachment capacity: 900 kg
For attachment assembly, operating and maintenance instructions, refer to the
relevant manual.
WARNING! For machines equipped with stabilisers, the use of this
attachment is foreseen with the machine properly stabilized.
This attachment has a rated load capacity lower than the maximum load
capacity of your machine. Therefore, before installing the attachment,
please check that your machine is equipped with a load limiter.
All load charts refer to the machine standing still on flat, firm ground, with
its wheels aligned with its chassis.
