9 - HYDRAULIC CIRCUIT DIAGRAMS
9 - 7
REFERENCE DESCRIPTION
1
Inlet filter
2
Return filter
3
Variable delivery pump
4
ENGINE
12
Volume recovery valve
17
Power steering unit
18
Steering distributor
19
Steering jack
22
Pressure gauge
23
Main distributor
24
Extension jack lock valve
25
Lifting jack
26
Throttle ø1mm
27
Extension jack
29
Chassis side movement jack
30
Fork / compensation (offset) valve
31
Compensation (offset) jack
32
Fork jack lock valve
33
Fork jack
36
Front fast-acting couplings
37
Front fast-acting couplings
42
Quick coupling
63
Stabilisers jack lock valve
64
Stabiliser jacks
67
Quick-uncoupling jack
68
Lifting jack lock valve
69
Levelling distributor
90
Pressure connection
94
Accumulator
96
Angle correction jacks
97
Angle correction jack block valves
102
One-way choke valve
144
Emergency over-ride solenoid
154
3-way capacity adjustment valve
