4 - COMMANDS AND INSTRUMENTS
4 - 4
• WINDSCREEN OPENING
- turn the lever "A" through 45°
- open the windscreen slightly
- move the lever "A" in the horizontal position
- push the windscreen forward up to the automatic stop position.
• WINDSCREEN CLOSING
- turn the lever "A" through 45°
- close the windscreen slightly
- move the lever "A" in the horizontal position
- close the windscreen by pulling it backwards up the rest position.
• REAR WINDOW OPENING
Rotate the lever (A) to the left, then open the window pushing it forward to the
desired position.
• REAR WINDOW CLOSING
Rotate the lever (A) to the right to the automatic stop position.
• CAB LIGHT
The cab courtesy light "P" is located in the right upper part of the roof lining.
The light has 3 positions:
a) left position: light off
b) central position: light off
c) right position: courtesy light on
The cab courtesy light can be switched on even when the instrument panel is
switched off.
CAB VENTILATION
The cab ventilation is granted by the outlets present on the dashboard and under the seat.
Press to lift fins, then adjust the outlet in the desired position.
