Micrel Rhythmic evolution - Page 100

Soft key function depends on the respective display
symbol or label.
Purge - Bolus button
Start / Stop button
Battery level indicator
Rythmic™ Evolution supplied from the DC adaptor
Rythmic™ Evolution supplied from IP Connect Pack
External power adaptor inlet/ RS 232 output
Battery type
IEC 6LR61
Battery polarity
Bolus inlet
Key inlet
98 99
BOLUS
PCA
Ι +
