10.6 Using IV pole clamp.
82 83
Rythmic™ Evolution Organiser
Ensure the pole clamp is secured to an IV pole able to
sustain the pump and bag weight.
• Securely fix the pole clamp on the IV pole.
• Introduce the 4 inserts located at the rear side of the
pump and slide down until a “click” is heard.
• Ensure the pump is fully secured in the pole clamp
and that the extension lines are not trapped in pole
clamp.
• The IV pole clamp provides a location to store the
Micrel Power Adaptor when not in use.
The pump can be securely lock to the pole clamp.
• To unlock the pump from the pole clamp push the
black knob located in the transparent cover and
pull the pump outward and upward, as shown in the
pictures below.
Rythmic™ Evolution and Mini Rythmic™
Evolution
Fit the pump with the display visible. Ensure the pump
is fully secured in the pole clamp and that the extension
lines are not trapped in pole clamp.
