All administration sets are single use products, sterile using ethylenoxide and are
equipped with:
An in line air eliminating filter to ensure that any air trapped within the fluid is not
delivered to the patient.
Anti-siphon valve to prevent free flow, if the set is removed unclamped from the
pump while still connected to the patient.
Silicon pumping segment to achieve infusion accuracy
Anti-kinking extension line
Slide clamp
Protective caps
The Rythmic™ Administration Set is a single use product and shall be replaced according
to the treatment protocol and the healthcare provider's policy for infection control. The
Rythmic™ Administration Set shall be replaced earlier than 7 days of use.
20 21
6
2
4
1
5
3
!Caution
When handling fluid-path connections always follow aseptic technique protocol.
