Micsig TO1102 - Introduction Basic Operations of Touch Screen

12
No.
Description
point
7
Center line of waveform display area
8
Memory depth indicatrix
9
Current trigger type indication
10
Current trigger source, trigger level
11
Trigger level indicator
12
CH1、CH2、CH3、CH4 cchannel icons and vertical sensitivity icon. Tap the channel icons to
open channels and corresponding channel menu, or close channels, operate in a loop; Tap mV or
V to adjust the vertical sensitivity of channels; Display the vertical sensitivity of channels; Display
the sampling mode
13
Trigger level adjustment, press on the button to modify the trigger level through upward and
downward movements
14
Display areas of USB-PC connection, USB connection, battery level, time etc.
15
Switch to MATH and REF channel
16
Horizontal and vertical cursors open and close
17
Current channel selection. Click to pop up the current channel switching menu to switch the current
channel.
18
Horizontal time base control icon. Tap the left/right time base buttons to adjust the horizontal time
base of the waveform. Tap the time base to turn on the time base knob and turn the knob to adjust
the time base.
19
Quick save. Tap to quickly save the waveform as a reference waveform.
20
Fine adjustment button. Tap the button to finely adjust the last operation, including waveform
position, trigger level position, trigger point and cursor position.
21
Waveform display area displays information such as waveforms, cursors, and related waveform
measurements.
22
Channel indicator can indicate the zero-level position of the open channel.
Table 2-1 Description of Oscilloscope Display Interface
2.7 Introduction Basic Operations of Touch Screen
The tBook mini Series oscilloscope operates mainly by tap, swipe, single-finger drag, and multi-finger drag.
