Chapter 2. Quick Start Guide of Oscilloscope
19
Figure 2-15 Probe Adjustment
The safety ring on the probe provides a safe operating range. Fingers should not exceed the safety ring when
using the probe, so as to avoid electric shock.
6) Connect the probe to all other oscilloscope channels (Ch2 of a 2-channel oscilloscope, or Ch 2, 3 and 4 of a
4-channel oscilloscope).
7) Repeat this step for each channel.
Warning
⚫ Ensure the wire insulation is in good condition to avoid probe electric shock while measuring high
voltage.
⚫ Keep your fingers behind the probe safety ring to prevent electric shock.
⚫ When the probe is connected a voltage source, do not touch metal parts of the probe-head to prevent
electric shock.
⚫ Before any measurement, please correctly connect the probe ground end.
2.15 Modify the Language
To modify the display language, please refer to “11.4 Settings - Language”.
