signal rather than the frequency of the signal.
The following steps can be used to calculate the required oscilloscope bandwidth:
1) Determine the fastest edge speed.
Rise time information is typically obtained from the published device specifications used in the design.
2) Calculate the maximum “actual” frequency component.
According to Dr. Howard W. Johnson’s book “High-Speed Digital Design–A Handbook of Black Magic”,
all fast edges have wirelessly continuous frequency components. However, there is a turning point (or
“inflection point”) in the fast edge spectrum at which frequency components above f
knee
are negligible in
determining the signal shape.
f
knee
=0.5/signal rise time (based on 10% - 90% threshold)
f
knee
=0.4/signal rise time (based on 20% - 80% threshold)
3) The multiplication factor for the desired accuracy is used to determine the required oscilloscope bandwidth.
Table 10-1 Bandwidth Corresponding to Oscilloscope Measurement Accuracy
10.2 Run/Stop Key and Single SEQ Key
Use softkeys in the button area to start and stop the oscilloscope acquisition system: Run/Stop button
and Single Sequence Acquisition button.
⚫ When the Run/Stop button is displayed in green, it indicates that the oscilloscope is running,
that is, it meets the trigger condition and data acquisition is being performed. The green “ ” or “ ”
is displayed in the upper left corner of the screen.
To stop data collection, tap the Run/Stop button. After stopping, the screen displays the last acquired
waveform.
⚫ When the Run/Stop button is displayed in red, it indicates that data acquisition has stopped.
The red “ ” is displayed in the upper left corner of the screen.
To resume data acquisition, press the Run/Stop button again.
