rising edge, falling edge
polarity: positive, negative, arbitrary
rising edge, falling edge, arbitrary
positive, negative, arbitrary
odd field, even field, all fields, all lines, lines
System: pal, NTSC, SECAM, 720p, 1080i, 1080p
UART(RS232/RS422/RS485) is triggered on the
transmission start bit, stop bit, data, 0 data, 1 data, X
data and parity error within 10 Mb / s.
Lin (optional) is triggered within 100 kb / S (20 KB /
s as defined by Lin) on synchronous rising edge,
frame ID, frame ID and data.
Can (optional) can signal frame start, frame type
(data, remote, error, overload), identifier (standard or
extended), data, identifier and data, frame end,
missing ACK or bit filling error within 1 MB / s.
You can further specify that the data is used to trigger
when ≤, ＜, =, >, ≥ or ≠ a special data value. The user
adjustable sampling point is set to 50% by default.
SPI (optional) is activated on the SPI bus within 50.0
MB / s on SS, frame start, MoSi, miso or MoSi and
miso.
I2C (optional) is triggered on start, repeat start, stop,
lost ACK, address (7 or 10 bits), data or address and
data on I2C bus within 10 Mb / s.
