162
1553Boptional
1553B (matching) in synchronization, word type 1
(command, status, data), command word (DB setting
RT address, T/R, sub address / mode, data word
number / mode code and parity), data word (user
specified 16 bit data value), error (synchronization,
parity, Manchester, discontinuous data), idle time (the
shortest time range can be 2 s s 100 μ s, the longest
time range can be selected from 2 μ s to 100 μ s,
which can be triggered in < minimum value, >
maximum value, in the range and out of the range).
RT address can be further specified to trigger when =,
≠, <, >, ≤, a special data value or within or outside
a certain range.
Trigger coupling mode
DC, AC, HF suppression, LF suppression, noise
suppression
Trigger hold-off time range
200ns~10s
measurement
Measurement type
cycle, frequency, rise time, fall time, positive duty
ratio, negative duty ratio, delay, positive pulse width,
negative pulse width, burst pulse width, positive
overshoot, negative overshoot, phase, peak peak peak
value, amplitude, high, low, maximum, minimum,
average, cycle average, root mean square, cycle root
mean square
Cursor type
horizontal cursor, vertical cursor, cross cursor
Math
FFT
4 windows:Rectangle Hanning Hamming
Blackman
Double waveform
+-*/
XY mode
X-axis input / Y-axis input
Channel 1CH1/Channel 2CH2
Storage
Waveform
Unlimited
Unlimited
